Description
**Please allow up to 2 weeks to ship**
Made in the UK
Photo is for reference, and is not for exact kit or contents
UNF – Unified National Fine Standard Thread
Each Set contains 2 Taps per size (Taper and Bottom lead), along with the corresponding round Die, appropriate Tap Wrench(es), and Die Stock(s).
They are manufactured in the United Kingdom, and are supplied in a wooden box with custom cut foam inserts.
| High Speed Steel – Ground Thread |
| Thread Form Size Range |
Part Number | Tap and Die Contents | Tap Wrenches |
Die Stocks |
|
UNF No. 3 – 12 |
TAPS-ETDS48 | 3, 4, 5, 6, 8, 10, 12 | No 0 | 13/16″ |
| UNF 1/4 – 1/2″ | TAPS-ETDS31 | 1/4, 5/16, 3/8, 7/16, 1/2″ | No 2 | 1″ |
| UNF 1/4 – 3/4″ | TAPS-ETDS35 | 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4″ | No 2 & 3 | 1″ & 1-1/2″ |
| UNF 1/4 – 1″ | TAPS-ETDS39 | 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1″ | No 2 & 4 | 1″, 1-1/2″ & 2″ |
Drills are sold separately CLICK HERE
(Sizes suggested are for approx. 75% thread)
TAP DRILL SIZES – INCH SIZES – NATIONAL FINE
----------------------------TAP DRILLSIZE SIZE----------------------------#0-80 3/64" #1-72 #53#2-64 #50#3-56 #46#4-48 #42#5-44 #37#6-40 #33#8-36 #29#10-32 #21#12-28 #151/4-28 #35/16-24 I3/8-24 Q7/16-20 W1/2-20 29/649/16-18 33/645/8-18 37/643/4-16 11/167/8-14 13/161"-14 15/161-1/8-12 1-3/641-1/4-12 1-11/641-1/2-12 1-27/641-3/4-12 1-43/642"-12 1-59/64----------------------------
