Description

Please select a size from the pull down menu

EZ Easy Read Tapes

• Designed for use in poor ambient light conditions where reading the graduations on standard tapes becomes difficult.
• The easy-read version is manufactured on a ‘blued’ steel with the acid etched graduations and numerals being filled with a white pigment.
• The blue background with white graduations and numerals makes reading the tape much easier, hence an easy-read tape.

The periphery tape, provides a quick, accurate and easy method of reading true diameters of both round and out-of-round forms.

• Perfect for measurement of thin or soft walled parts – large or small.
• Pi Tape gages consist of a narrow metal ribbon bearing special graduations.
  These graduations are designed to convert circumferential distance into diameter measurement so the observer can read the diameter directly from the scale.
• Tapes are checked over master gages at .001′”(.03mm) accuracy for standard tapes up to 144″ (3600mm).
  Certificate of accuracy traceable to National Institute of Standards and Technology is furnished.
• Pi Tapes require a minimum of maintenance, but we do recommend a quick wipe with an oil moistened cloth after use. A light gun oil works very well.
